Multifunctional N Surface And Underground Core Barrel System Approved ISO

1 set
MOQ
Negotiate
قیمت
Multifunctional N Surface And Underground Core Barrel System Approved ISO
امکانات گالری توضیحات محصول درخواست نقل قول
امکانات
مشخصات
Name: Core Barrel
Type: Conventional Core Barrel
Style: Wireline Core Barrel
Materials: European 4145 Steel Casing
Model: Q Series Core Barrel NQ, HQ, PQ Wireline Core Barrel
Metric: Bristish Metric Core Barrel
Standards: T 2-66, T 2-76, T 2-86, T 2-101, T 2-116; T6-76, T6-86, T6-101, T6-116
Core Barrels: Boart Longyear Core Barrel
Sweden Core Barrel: Atlas Copco Core Barrel, Atlas Copco Core Barrel
Tools: Wireline Coring Tools
Q 3 Series: HQ 3, NQ 3, PQ 3 Core Barrels
Triple Core Barrel: BMLC, NMLC, HMLC Triple Tube Core Barrels
برجسته:

,

,

drilling core barrel

اطلاعات اولیه
محل منبع: Germany,China
نام تجاری: ROSCHEN
گواهی: ISO, CE
شماره مدل: B N N2 N3 H H3 P P3
پرداخت
جزئیات بسته بندی: wooden box
قابلیت ارائه: 300 sets
توضیحات محصول

Multifunctional System For Standard And Pump-In Application Mincon Wireline Core Barrel

Coring Aftermarket Wireline Core Barrel NSW/N2SU/N3SU
Multifunctional System For Standard And Pump-In Application


The new multifunctional NSU (N surface and underground) core barrel system from Roschen features interchangeable components and offers standard and pump-in applications in a single system.

The NSU system will not only offer greater flexibility, but also a more cost-efficient solution, greater safety and increased productivity. The system is user-friendly and designed for safer handling. There is no need for different coring tool systems as this multifunctional system is ideal for both surface and underground applications.

At Roschen, we offer a superior product range and are always ready to assist you, wherever you are, thanks to our worldwide presence.

Thinner walls and tighter tolerances enable Roschen to offer a lighter weight core barrel, and when used with Roschen’s thin kerf bits, decreases the surface area for up to 30% faster penetration rates. These systems feature a number of unique innovations including ITIP valve for landing indication and integrated pump out for triple-tubes.

Roschen’s thin kerf coring systems offer many advantages for both surface and underground applications — the geologist can log a larger core sample from a similar sized hole and the driller is able to work under more ergonomic conditions. Contact your local Roschen representative to get more information.

Roschen recommends using only Roschen quality manufactured parts. Roschen does not guarantee the consistency or quality of other manufacturers.
Specifications:

System Hole Core
mm in mm in
A 48,0 1.89 27,0 1.06
B 59,9 2.36 36,4 1.43
N 75,7 2.98 47,6 1.88
H 96,1 3.78 63,5 2.5
P 122,6 4.83 85,0 3.35



Features:
1. Wireline system which affected the rod and core barrel design and incorporated the use of a wireline overshot.

2. Triple-tube system which effected the core barrel and the bit design and allowed for a second split inner tube to be used so that an undisturbed sample of very broken core could be viewed in its original state.
3. Thin kerf or light weight systems which effected the design and dimensions of the entire drill string to allow for a larger core sample to be retrieved at increased depths or in similar sized hole.
