Air Leg YT28 pneumatic rock drill
Air leg YT28 pneumatic rock drill
| Categories | Drilling Equipment |
| Place Of Origin: | China |
| Brand Name: | ROSCHEN |
| Certification: | CE MA |
| Price: | $500 |
| Packaging Details: | Wooden Case |
| Delivery Time: | 15days |
| Payment Terms: | T/T |
| Supply Ability: | 1000 |
| MOQ: | 1 ~ 5 |
YT 28 rock drill / Rock Drill / pneumatic drill / air leg rock drills
1. The rock drill is a kind ofhigh efficiency air leg rock drill machinery.
2. It is mainly used for blasting holes and other drilling works in aquarries, railway construction, water conservancy construction and defence project facility.
3. It is suitable for drilling and blasting under various of rocks and any direction angles.
4. Blast hole dia is 34 ~ 42 mm, drill hole depth is 5 meters.
5. This machine may match with FT160 BD short air lego FT160BC long air leg.
| Item name | YT28 |
| Weight | 26kg |
| Overall dimensions | 668mm |
| Stoke | 60mm |
| Cylinder Dia | 80mm |
| Air pressure | 0.4-0.63mpa |
| Water pressure | 0.4mpa |
| Impact energy | 75.5J |
| Torque (at0.4MPa) | |
| Impact frequency | >36Hz |
| Air consumption | 85L/S |
| Drilling speed | |
| Max drilling depth | >6m |
| Air pipe inside dia | 25mm |
| Water pipe inside dia | 13mm |
| Drill bit size | 32-42mm |
| Drilll rod size | H22X108mm |
| FT160 Air leg | |
| Weight | 17kg |
| Length | 1800mm |
Product Specifications:
| part name | model | Technology | weight | |
| kg | ||||
| pneumatic | rock drill | Y6 | wo leg | 6 |
| pneumatic | rock drill | Y8 | wo leg | 8 |
| pneumatic | rock drill | Y10 | wo leg | 10 |
| pneumatic | rock drill | Y12 | wo leg | 12 |
| pneumatic | rock drill | Y15 | wo leg | 15 |
| pneumatic | rock drill | YO18 | wo leg | 18 |
| pneumatic | rock drill | Y19A | wo leg | 19 |
| pneumatic | rock drill | Y20 | wo leg | 18 |
| pneumatic | rock drill | Y20LY | wo/wz leg | 18 |
| pneumatic | rock drill | YT23/7655 | wz leg | 24 |
| pneumatic | rock drill | YT23D/7655D | wz leg | 24 |
| pneumatic | rock drill | Y24 | wo leg | 24 |
| pneumatic | rock drill | Yt24 | wz leg | 24 |
| pneumatic | rock drill | Y26 | wo leg | 26 |
| pneumatic | rock drill | YT27 | wz leg | 27(35) |
| pneumatic | rock drill | YT28 | wz leg | 28 |
| pneumatic | rock drill | YT29 | wz leg | 28 |
| pneumatic | rock drill | YSP45 | wo leg | 44 |
| pneumatic | rock drill | QJ15 | wo/wz leg | 15 |
| pneumatic | rock drill | YL18 | wo/wz leg | 18 |
| pneumatic | rock drill | YH24 | wo leg | 24 |
| gasoline | rock drill | YN27C | wo leg | 41 |
| 2. The pneumatic breakers andhammers: | ||||
| part name | model | Technology | weight | |
| kg | ||||
| pneumatic | breaker | CP1210/B47 | Chicage Construction Pneumatic | 21.5 |
| pneumatic | breaker | B67C | Gardner Denver | 30 |
| pneumatic | breaker | B87C | Gardner Denver | 39 |
| pneumatic | breaker | MX60a/b | Ingersoll Rand | 31.4 |
| pneumatic | breaker | MX90a/b | Ingersoll Rand | 39 |
| pneumatic | breaker | PB35 | Ingersoll Rand | 20 |
| pneumatic | breaker | PB50 | Ingersoll Rand | 25 |
| pneumatic | breaker | SL80 | Germanmy | 37 |
| pneumatic | breaker | Tex32/B70 | Atlas Copco | 29 |
| pneumatic | breaker | Tex42/B90 | Atlas Copco | 34 |
| pneumatic | breaker | TPB-40/B50 | Japan Toku | 18 |
| pneumatic | breaker | TPB-60 | Japan Toku | 30 |
| pneumatic | breaker | TPB-90 | Japan Toku | 42 |
| pneumatic | hammer | TCA-7 | Japan Toku | 7.2 |
| pneumatic | hammer | TCA-100 | Japan Toku | 10.5 |
| pneumatic | hammer | SK-10 | Ameriac Sullair | 10 |
| pneumatic | hammer | G7 | 7.2 | |
| pneumatic | hammer | G10 | 10.5 | |
| pneumatic | hammer | G20 | 20 | |
| pneumatic | chipper | QD30-1 | 5 | |
3. Drill bits: We have the cross drill bits; chisel bits, button bits, tricone bits. Drill rods, Integral drilling rods tapered drilling equipment, extension drilling equipment, shank adapters and coupling.
